Covers Quality

The quality of conveyor belts and their covers can vary significantly, and understanding these differences is crucial to select the right belt for your specific needs. It is the quality of these covers that determines the lifespan of the belt.

At SIBAN we manufacture a wide range of high quality, standard-compliant conveyor belts designed to meet the needs of your industry, ensuring efficient and safe conveying solutions. In addition, we have our own laboratory to carry out all the necessary tests and measurements.

All our belts comply with ATEX standards. They are designed to provide a safe and reliable solution for conveying materials in potentially explosive environments.

Abrasion Resistant

In the conveyor belt industry, abrasion resistance is essential to ensure durability and optimum performance in demanding environments. The physical ability of a conveyor belt to resist wear is the single most important factor determining its durability and therefore its price quality relation.

Our abrasion resistant conveyor belts are manufactured in accordance with DIN 22102 and ISO 14890, making them the ideal choice for applications where extreme wear conditions are faced.

Conveyor belts manufactured by SIBAN are available in different grades of abrasion resistant quality according to DIN standard.

Y : For conveying materials under normal conditions

X : For conveying heavy materials with impact and sharp edges. Excellent cut and impact resistance.

W : For conveying highly abrasive materials such as sands.

Overall* : Own grade slightly higher than DIN Y

Stone* : Own Grade slightly higher than DIN X

RI* : Proprietary anti-impact grade, for heavy and bulky materials.

Oil and Grass Resistant

Oil resistance of conveyor belts is very important to ensure optimal and safe performance in areas where lubricating fluids or other oily products are stored.

When oil penetrates the conveyor belt it causes swelling and deformation leading to stability problems and deflections, as well as premature wear. Oils and greases that exhibit these harmful effects can be divided into two distinct sources: mineral and vegetable/animal.

The oil resistant conveyor belts manufactured by SIBAN can withstand both materials containing vegetable oils (MOR quality) and those containing both animal and mineral oils (G quality).

According to the DIN 22102 standard, we have the following grades;

MOR: Medium oil resistance

BG: Medium-high resistance to oil.

BGM: Maximum oil resistance. For highly aggressive mineral oils and the transport of products with high concentrations of vegetable oil.

BGT: Resistance to oil and high temperatures (150°C) according to ISO 4195 Class 2

BEIGE*: Specific grade suitable for applications where it is necessary to avoid staining the transported product (paper, cardboard, wood). Maximum oil resistance



Heat Resistant

Heat resistant conveyor belts are essential to ensure the safe and efficient transport of materials in industrial environments where extreme heat is a constant concern. These belts are designed to withstand high temperatures and offer reliable performance making them ideal for a wide range of industrial applications such as metallurgy, glass, ceramics and other sectors.

High temperature resistant conveyor belts are classified according to ISO 4195 into different classes according to the test temperature. It is important to understand that the resistance of the belt does not only depend on the temperatures to which it is exposed, but also on the conveyed material, the operating conditions and the type of contact.

The Heat Resistant belts manufactured by SIBAN are resistant to materials with medium and high temperatures and temperature peaks from 130ºC to 250ºC depending on the model selected (T1, T2, T3).

We have also developed our own grades such as:

Endure Heat*: equivalent to a T2 in terms of thermal resistance but offering better mechanical performance.

Super Heat*: equivalent to a T3 in terms of thermal resistance but offers a better abrasion rate.

For Food Industrie

In the food industry, safety and hygiene are top priorities. Food conveyor belts play a crucial role in the safe and efficient transport of food products, from raw materials to finished products. These belts are designed to meet strict hygiene and food safety regulations, ensuring that products reach consumers in perfect condition.

The manufacturing of conveyor belts is based on the European standard CE 1935. Our belts have been tested by independent national and international independent laboratories, proving their compliance with BFR Title XXI and allowing us to issue the ANIA declaration for products intended for food contact.

Our belts are designed to withstand weathering and ozone attack and are FDA certified.

WF: White food grade.

WFG: Anti-oil and anti-static white food grade.

WFKG: Flame retardant white food, oil and static resistant.

We can also manufacture Food Belts in Blue or Green according to the customer’s needs.

Flame Resistant

In industrial environments where fire safety is very important, flame resistant conveyor belts are essential. These belts are made to meet safety norms and standards to protect employees and assets in case of an emergency.

Flame retardant belts manufactured by SIBAN are available in the following grades according to DIN 22102 and in accordance with ISO EN 12882 -2A-2B.

K: For the transport of fire and explosion hazardous materials. EN 12882 2A

S: For explosive materials and in mines. EN 12882 2B

KABR*: Own grade which improves the performance of K grade with a better abrasion index.

SABR*: Own grade that improves the performance of S grade with an improved abrasion index.

MFR*: Own grade that is certified according to MSHA 30 CRF-14 (Mine Safety and Health Administration, USA).

In addition, we also manufacture conveyor belts that combine oil resistant and fire resistant properties; K+MOR, S+MOR, K+BG, S+BG

Cold Resistance

Cold resistant conveyor belts play a vital role in a wide variety of industries, where low temperatures can affect the performance and durability of conveying equipment. The belts, designed to DIN 22102 and ISO 14890 standards, are designed to withstand extreme cold conditions and provide efficient conveying in low temperature environments.

These belts are especially useful in environments where temperature sensitive materials such as frozen foods, pharmaceuticals and cold sensitive chemicals need to be conveyed.

Low temperature resistant conveyor belts manufactured by SIBAN are suitable for conveying materials in a temperature range from -50ºC to +50ºC.
